Auto Tool Changer ATC CNC Router Machine With SIEMENS Control System

Name: Auto Tool Changer ATC CNC Router Machine With SIEMENS Control System
Brand: BLUE ELEPHANT
Price: 15999 USD

Brand Name : BLUE ELEPHANT

Model Number : ELE1530

Certification : CE, ISO9001，SGS，CIQ

Place of Origin : Jinan City, Shandong Province,China

MOQ : 1set

Price : 15999-29999$

Payment Terms : L/C, D/A, D/P, Western Union, T/T, MoneyGram

Supply Ability : 200sets per Month

Delivery Time : 15-20days

Packaging Details : Plywood case package for exporting cnc wood router atc.

Delivery Detail : 7 working days after confirming payment.

Drive motor : 1kw Germany Siemens servo

control system : Germany Siemens

electronic parts : France Schneider electronic spare parts; Japan OMRON switch

spindle : original imported 9kw Italy HSD ATC spindle,0-24000rpm

Contact Now

New type cnc auto tool changer machine with SIEMENS control system 808D high performance machine 1530

Features

1 . 9kw original imported Italy HSD ATC spindle.
World best brand,has after-sale service all over the world.Match with 11kw Taiwan DELTA inverter.
2 . Germany Siemens 808D control system.
With advanced control panel,even there's sudden electricity power-off,you needn't reset from beginning.
3 .1KW Germany Siemens servo motors and drivers.
Match with Siemens control system,which provide the strongest power for machine .
4 . Taiwan HIWIN linear rail 25#.
Smooth and precise transmission,low noise and lifetime is 10 times longer than common rail way.

Applications

1 . Advertisement: engraving and cutting of various labels and number plate, marble, etc for artistic effects on materials including marble, brass, steel, and other metallic material.
2 . Crafts: engraving characters of any language and patterns on gifts and souvenirs, primitive processing and
shaping of artistic crafts, and stiletto.
3 . Moulding: engraving delicate letter and flower pattern, primitive and fine processing of the small mould.
4 . Architectural models: engraving fine window, fencing and wall patterns, etc.
5 . Seal: engraving seals and medal on materials such as buffalo horn, wood etc.
6 . Label: engraving character, number, and other pattern on label for products and on product directly.
7 . Wood processing: processing density board, stiletto for surfing board, processing of marbles, cabinet and furniture.

FAQ
1) This is the first time I use this kind of machine, is it easy operate?
There are english manual or guide video that show how to use machine. If there is still have any question, we can talk from phone or skype.
2) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem. Free after-sales service life for machine, please feel free contact us if your machine have any problem. we will give you 24hours service from phone and skype.
Parameters

work area	15003300220mm
spindle	original imported 9kw Italy HSD ATC spindle,0-24000rpm
tool collet	ISO30
Max.rapid travel rate	60000mm/min
Max.working speed	25000mm/min
Travelling positioning accuracy	±0.03/300mm
Repositioning accuracy	±0.03mm
table surface	vacuum & T-slot working table
X,Y axis	helical rack transmission; Taiwan HIWIN linear rail
Z axis	Taiwan TBI ballscrew transmission; Taiwan HIWIN linear rail
inverter	11kw Taiwan DELTA inverter
Drive motor	1kw Germany Siemens servo
control system	Germany Siemens
tool change type	linear auto tool change system
tools number	8 positions ATC
electronic parts	France Schneider electronic spare parts; Japan OMRON switch
cable	highly flexible towline; fire-resistant double-sheathed cable
software	Type3,Artcam

Auto Tool Changer ATC CNC Router Machine With SIEMENS Control System
